On the Intel USB3.1 controller, there are a total of two on the back panel, a Type-A and Type-C. There are two of those located on the back panel, red, and are Type-A slots. The USB3.1 ports are managed by the ASMedia USB3.1 controller. A total of eight USB3, four at back panel, blue, four at mid-board and six USB2 (all six at mid-board) which are all driven by the Intel chipset. There are plenty of USB ports on this board.
#Maximus viii extreme formula problems software#
It also comes with the Sonic Studio II and Sonic Radar II (the latter an occasionally controversial software – in professional gaming anyway – that shows on screen where sounds are coming from). On the back of the board you find a typical fare of gold plated jacks along with an Optical S/PDIF port. It uses the ESS ES9023P DAC, and Texas Instruments TI RC4580 2VRMS audio OP AMP(s). The audio used on the board is of ASUS’ own flavor, the ROG Supreme FX 2015. The board also comes with a built in ASUS 3tR dual band Wi-Fi moving antennas that are 802.11a/b/g/n/ac compliant. This port also has the Anti-Surge LANGuard which helps prevent death by electric shock. The network consists of Intel’s latest NIC, the I219V Gigabit LAN controller, which supports GameFirst technology for network traffic management. It supports both SATA and PCIe mode as well. As mentioned in the introduction, it also comes with 1x M.2 x4 socket 3 with M Key that supports up to 110mm storage devices. There are two SATA Express ports shared with four more SATA ports. The six from the chipset support RAID 0, 1, 5, and 10. Six come from the chipset, while two more come from the ASMedia ASM1061 controller. First, it has a total of eight standard SATA 6Gb/s ports (gray). Of course, there is the onboard solution that supports up to 4K resolution with HDMI and Displayport connectivity.įor storage, the M8E sports a plethora of ports in a couple of different flavors. There doesn’t appear to be a PLX chip on the board so the NVIDIA solution will have to be by two dual-GPU cards as the green team doesn’t run on 4x slots (what the last slot breaks down to when running four cards).
#Maximus viii extreme formula problems full#
It does this using a total of four full length PCIe slots. On the graphics side of things, the board supports up to Quad GPU SLI from NVIDIA and 4-Way CrossfireX from the AMD camp. Now, you may not reach those speeds with the full allotment of RAM, but for those with more sane amounts, with the right CPU, you most certainly can get there. As is the status quo for this chipset, there are a total of four DIMM slots supporting a maximum of 64GB of Non ECC, Un-buffered DDR4 memory at speeds up to 3866 MHz (OC).
See what I did there? Ok, terrible jokes regarding our standard framework aside, we see the obvious out of the gate in that the Z170 based board supports Intel Socket 1151 6th Generation CPUs (AKA – Skylake based like the 6600/6700K). We will change things up in this review and start of with the Specifications table as shown at the ASUS website for the M8E.
It is now time to get comfy in your favorite chair and see what this board can do! Specifications The M8E promises to provide both the extreme overclocker and the enthusiast gamer with everything they need to beat world records under sub-ambient cooling, or game with the best of them. Type-C), M.2 slot, DDR4 support and a slew of others you will see, and we will discuss just a few flicks of the webwheel down the article. As is the case with past versions of this board, it comes chock-full of all the features the latest chipset offers including USB3.1 Gen2 (inc. I never had the pleasure to work on one before, believe it or not! I’ve worked with other boards in its class however, so it will be nice to see how this feels in my hands versus the other boards. Folks, I’m not going to lie, I was pretty excited to get my hands on ASUS’ flagship Z170 board, the Maximus VIII Extreme (M8E as I will call it moving forward), to test it out to see what it will do.
